What is a Thermocouple?

By Admin on

                                     A thermocouple circuit is formed when two dissimilar metals are joined at both ends and there is a difference in temperature between the two ends. This difference in temperature creates a small current and is called the Seebeck effect after Thomas Seebeck who discovered this phenomenon in 1821.


When there is a difference in temperature between the two ends of this circuit, a small voltage is formed within the circuit. This voltage or EMF (electro motive force) is usually measured in the 1/1000th of a volt (millivolt). Most people’s body produces more voltage than that! The higher the difference in temperature, the higher the voltage. If the right pairs of materials are used, these thermocouple circuits can be used to measure temperature.


The junction that is put into the process in which temperature is being measured is called the HOT JUNCTION. The other junction which is at the last point of thermocouple material and which is almost always at some kind of measuring instrument, is called the COLD JUNCTION.
